| Model |
MYA-3WD |
MYA-5WD |
MYA-8WD |
MYA-10WD |
MYA-12WD |
| Cooling Capacity |
kW |
5.2 |
7.8 |
13.5 |
16 |
20.5 |
| 103kcal/h |
4.47 |
6.71 |
11.61 |
13.76 |
17.63 |
| Power Supply |
V/ph/Hz |
380/3/50 |
| Input Power |
kW |
3 |
4.5 |
6.75 |
8.6 |
10 |
| Compressor Type |
Scroll |
| Compressor Power |
kW |
2.25 |
3.75 |
6 |
7.5 |
9 |
| Pump Power |
kW |
0.55 |
0.55 |
0.75 |
0.75 |
1.15 |
| Pump Head |
m |
22.5 |
21 |
25.5 |
22.5 |
24 |
| Chilled Water Flow |
m3/h |
1.5 |
2.5 |
3.5 |
4.5 |
5.5 |
| Cooling Water Flow |
m3/h |
1.8 |
3 |
4.2 |
5.4 |
6.6 |
| Evaporator Type |
Water Tank Type/Shell and Tube Type/Stainless Steel Plate Type |
| Water Tank Volume |
L |
55 |
90 |
120 |
200 |
200 |
| Pipe Size |
DN |
25 |
25 |
32 |
40 |
40 |
| Condenser |
Shell and Tube Type/Double-pipe Type |
| Refrigerant |
R22/R407C |
| Throttle Mode |
Capillary Tube/Expansion Valve |
| Protector |
Pressure,Overload,Anti-freeze,Delay,Over-temperature,Water Flow |
| Noise Level |
dB?(A) |
52 |
52 |
58 |
58 |
60 |
| Weight |
kg |
130 |
155 |
280 |
400 |
520 |
| ? |
L |
mm |
900 |
900 |
1150 |
1180 |
1180 |
| Dimensions |
W |
mm |
520 |
520 |
710 |
720 |
720 |
| ? |
H |
mm |
850 |
850 |
1200 |
1350 |
1350 |
| ? |
? |
? |
? |
? |
? |
? |
? |
| ? |
? |
? |
? |
? |
? |
? |
? |
| ? |
? |
? |
? |
? |
? |
| Model |
MYA-15WD |
MYA-20WD |
MYA-25WD |
MYA-30WD |
MYA-40WD |
| Cooling?Capacity |
kW |
25 |
34.5 |
40.5 |
48 |
58 |
| 103kcal/h |
21.5 |
29.67 |
34.83 |
41.28 |
49.88 |
| Power Supply |
V/ph/Hz |
380/3/50 |
| Input Power |
kW |
12.75 |
17.5 |
21 |
26.5 |
33 |
| Compressor Type |
Scroll |
| Compressor Power |
kW |
11.25 |
15 |
18.75 |
22.5 |
30 |
| Pump Power |
kW |
2.25 |
2.25 |
2.25 |
2.25 |
3.75 |
| Pump Head |
m |
27.5 |
27 |
26.5 |
25.5 |
28.5 |
| Chilled?Water?Flow |
m3/h |
7.5 |
9 |
10.5 |
13 |
18 |
| Cooling Water Flow |
m3/h |
9.8 |
11.7 |
13.6 |
17 |
23.4 |
| Evaporator Type |
Water Tank Type/Shell and Tube Type/Stainless Steel Plate Type |
| Water Tank Volume |
L |
280 |
350 |
350 |
420 |
480 |
| Pipe Size |
DN |
50 |
50 |
65 |
65 |
80 |
| Condenser |
Shell and Tube Type/Double-pipe Type |
| Refrigerant |
R22/R407C |
| Throttle?Mode |
Expansion?valve |
| Protector |
Pressure,Overload,Anti-freeze,Delay,Over-temperature,Water?Flow |
| Noise Level |
dB(A) |
62 |
62 |
65 |
65 |
65 |
| Weight |
kg |
650 |
800 |
880 |
1000 |
1150 |
| ? |
L |
mm |
1700 |
1850 |
1850 |
1950 |
2000 |
| Dimensions |
W |
mm |
750 |
750 |
820 |
910 |
950 |
| ? |
H |
mm |
1800 |
1800 |
1950 |
1950 |
1950 |
| Introductions： |
| ? |
? |
? |
? |
? |
? |
? |
? |
| The cooling capacity is based on a 35℃ entering cooling water temperature,a 30℃ leaving cooling water temperature,a |
| 0℃ entering chilled water temperature and a –5℃ leaving chilled water temperature. |
